Metal Lathe

BT410A High precision lathe machine in china poreba

Models:BT410A
Swing over bed:410mm
Swing over cross slide:220mm
Swing in gap diameter:640mm
Length in gap:165mm
Distance between centers:1000mm(40")/1500mm(60")/2000mm(80")
  • Product Detail
  • Accessories

Turning diameter (Max.) Ø410mm
Swing over cross slide Ø220mm
Swing in gap diameter Ø640mm
Valid length of gap 165mm
Distance between centers 1000/1500/2000/3000mm
Center heigh 205mm
Width of bed 300mm
Spindle nose D1-6
Spindle bore Ø58mm
Taper of spindle bore MT6
Spindle speed (12 steps) 25~2000rpm
Top slide travel 128mm
Cross slide travel 285mm
Max. section of tools 25x25mm
Range of metric threads (41 kinds) 0.1~14mm
Range of inch threads (60 kinds) 2~112T.P.I
Lead screw thread 6mm or 4T.P.I
Tailstock quill diameter Ø60mm
Tailstock quill travel 130mm
Taper of tailstock quill MT4
Motor power 5.5kw
Coolant pump power 100w
Voltage 380V~440V (3PH)
Packing size (2200/2800/3300)x1120x1560mm

Standard Accessories
3-jaw chuck (Ø200/250mm)
Steady rest (Ø25~178mm)
Face plate (Ø350mm)
Foot brake
Splash guard
4-jaw chuck (Ø250/300mm)
Follow rest (Ø19~114mm)
Coolant / Lamp system
Chuck cover
Toolbox & tools set
