Metal Lathe

BT320 Cheap price metal turning lathe machine with cooling system

Models:BT320
Swing over bed:330mm(13")
Swing over cross slide:198mm(7-25/32")
Swing in gap diameter:476mm(18-34")
Length in gap:210mm(8-1/4")
Center height:166mm(6-1/2")
Distance between centers:1000mm(40")
Spindle nose:D1-4 Or D1-5
Taper of spindle bore:No5 morse
Spindle bore:38mm(1-1/2") Or 51mm
  • Product Detail
  • Accessories

BT320 Cheap price metal turning lathe machine with cooling system
1)Widely useful, like home hobby, Education, Factory use ect, operation easy.
2)Various speeds and thread cutting function are avaiable with gear box.
3)Induction-hardened and ground prismatic bed made from cast iron.
4)High precision and hardened spindle.
5)Safety magnetic and lock key European-standard switch.
6)Cost-efficient,precise and stable value.

Turning diameter (Max.) Ø330mm
Swing over cross slide Ø198mm
Distance between centers 1000mm
Center heigh 166mm
Width of bed 187mm
Spindle nose D1-4
Spindle bore Ø38mm
Taper of spindle bore MT5
Spindle speed (8 steps) 70~2000rpm
Top slide travel 95mm
Cross slide travel 170mm
Max. section of tools 16x16mm
Range of metric threads (44 kinds) 0.1~7mm
Range of inch threads (42 kinds) 4~112 T.P.I
Lead screw diameter Ø22mm
Lead screw thread 3mm or 8T.P.I
Tailstock quill diameter Ø32mm
Tailstock quill travel 100mm
Taper of tailstock quill MT3
Motor power 1.5kw
Voltage 380V~440V (3PH)
Packing size (1680/1930)x760x1580mm




Standard Accessories
Optional Accessories
3-jaw chuck
4-jaw chuck
Dead center
Change gear set
Wrench set
Oil can
Splash guard
Chip tray
Follow rest
Steady rest
Face plate
Toolbox &tools
Stand
USA Quick change tool post
Lead screw cover
Working lamp
Cooling pump
MT3 Rolling center
CE Standard
51 spindle bore
Foot brake
Holder guard
Digital readout(2 axis)
Digital readout(3 axis)
Tapet turning attachment
