BT800 Metal turning lathe machine used universal horizontal lathe machine for sale

Model No.:BT660
Swing over bed:Ø800mm(31-1/2")
Swing over cross slide:Ø570mm(31-1/2")
Swing in gap diameter:1035mm(40-3/4")
Valid length of gap:250mm(10")
Distance between centers:1500mm(60'') 2000mm(80") 3000mm(120")
Width of bed:400mm(15-13/16'')

Product Detail

Turning diameter (Max.)	Ø800mm
Swing over cross slide	Ø570mm
Swing in gap diameter	Ø1035mm
Distance between centers	1500/2000/3000mm
Center heigh	400mm
Width of bed	400mm
Spindle nose	D1-8
Spindle bore	Ø105mm
Taper of spindle bore	Ø113 (1:20)
Spindle speed (12 steps)	25~1600rpm
Top slide travel	230mm
Cross slide travel	420mm
Max. section of tools	25x25mm
Range of metric threads (54 kinds)	0.45~120mm
Range of inch threads (54 kinds)	7/16~80T.P.I
Lead screw thread	12mm or 2T.P.I
Tailstock quill diameter	Ø90mm
Tailstock quill travel	235mm
Taper of tailstock quill	MT5
Motor power	7.5/11kw (Optional)
Coolant pump motor	100w
Voltage	380V~440V (3PH)
Packing size	(3240/3740/4740) x1140 x1840mm

Standard Accessories

3-jaw chuck (Ø315mm)
Steady rest (Ø20~190mm)
Face plate (Ø450mm)
Foot brake
Splash guard
4-jaw chuck (Ø400mm)
Follow rest (Ø20~130mm)
Coolant / Lamp system
Chuck cover
Toolbox & tools set
