Jiangsu Bestech Industrial Co., Ltd.
| Mill & Drill | |
| Max. drilling capacity | Iron Ø40mm / Steel Ø32mm |
| End milling capacity | Ø32mm |
| Face milling capacity | Ø80mm |
| Spindle taper | MT3/MT4/R8 |
| Spindle travel | 120mm |
| Range of spindle speed | 75~1600rpm/75~3200rpm (Optional) |
| Head tilt left and right | ±90° |
| Step of spindle speeds | 6 /12 (Optional) |
| Automatic spindle feeds | 0.1/0.18/0.26mm/r |
| Worktable | |
| Working table size | 730×210mm |
| Worktable X/Y-Axis travel | 500×230mm |
| T-slot | 12mm |
| Distance between spindle and column | 260mm |
| Max distance spindle to table | 430mm |
| Motor power | 1100w |
| Cooling motor | 40w (Optional) |
| Packing size | 820×760×1150mm |
| N.W/G.W | 270/300kg |
