Jiangsu Bestech Industrial Co., Ltd.
| Turning diameter (Max.) | Ø400mm |
| Swing over cross slide | Ø266mm |
| Distance between centers | 1000mm |
| Center heigh | 200mm |
| Width of bed | 206mm |
| Spindle nose | D1-5 |
| Spindle bore | Ø52mm |
| Taper of spindle bore | MT6 |
| Spindle speed (16 steps) | 45~1900rpm |
| Top slide travel | 95mm |
| Cross slide travel | 180mm |
| Max. section of tools | 16x16mm |
| Range of metric threads | 0.45~7.5mm |
| Range of inch threads | 4~112 T.P.I |
| Lead screw diameter | Ø22mm |
| Pitches of feed lead screws | 4mm or 8T.P.I |
| Tailstock quill diameter | Ø45mm |
| Tailstock quill travel | 120mm |
| Taper of tailstock quill | MT3 |
| Motor power (double motor) | 1.5/2.5kw |
| Voltage/AC | 380V~400V(3PH) |
| Packing size | 1930x920x1600mm |
